Usually, by clicking on some random track, the DRC error goes away, but I have spent a few days on this and can't solve it. There are cases where one has to just give up and accept some DRC errors but I don't like doing it. I wondered if one is supposed to use a Polygon Plane? I tried that and it doesn't seem to make any difference. The way to generate split planes is to place a track on the plane layer. I have carefully checked that the tracks placed on the Plane 1 layer have no breaks in them, since that would be an obvious cause. But Protel is in some cases joining them up - as if the planes were joined. I have this PCB with a split ground plane (Internal Plane 1): Placing pads in each these four areas, with all the pads having a "relief to Plane 1" should not produce a conflict.
Protel 99se polygon plane how to#
But now I have a weird problem and wonder if somebody of sufficient age might remember how to deal with it.
Protel 99se polygon plane trial#
I am also more than familiar with its cryptic and mostly useless DRC errors, which in most cases are solved by trial and error only the. It works great and I have done many many designs with it.
Protel 99se polygon plane software#
